| Cross-sectional area Nom. (mm²) | No. of wires x diameter Nom. (mm) | Conductor diameter (mm) | Insulation thickness (mm) | Overall diameter (mm) | Weight Approx. (kg/km) | Conductor resistance at 20°C Max. (Ω/km) |
|---|---|---|---|---|---|---|
| 5 | 7 x 9 x 0.32 | 3.1 | 0.6 | 4.3 | 57 | 3.58 |
| 9 | 7 x 16 x 0.32 | 4.2 | 0.6 | 5.4 | 99 | 2.00 |
| 15 | 19 x 9 x 0.32 | 5.3 | 0.6 | 6.5 | 150 | 1.32 |
| 20 | 19 x 13 x 0.32 | 6.5 | 0.6 | 7.7 | 210 | 0.915 |
| Cross-sectional area Nom. (mm²) | No. of wires x diameter Nom. (mm) | Conductor diameter (mm) | Insulation thickness (mm) | Overall diameter (mm) | Weight Approx. (kg/km) | Conductor resistance at 20°C Max. (Ω/km) |
|---|---|---|---|---|---|---|
| 9 | 7 x 16 x 0.32 | 4.2 | 1.0 | 6.2 | 109 | 2.00 |
| 15 | 19 x 9 x 0.32 | 5.3 | 1.1 | 7.5 | 161 | 1.32 |
| 20 | 19 x 13 x 0.32 | 6.5 | 1.1 | 8.7 | 225 | 0.915 |
