| No. of wires x diameter Nom. | Overall diameter |
|---|---|
| mm | mm |
| 8 x 16 x 0.05 | 0.8 |
| 8 x 23 x 0.05 | 1.0 |
| 8 x 32 x 0.05 | 1.2 |
| 8 x 48 x 0.05 | 1.35 |
| 8 x 64 x 0.05 | 1.55 |
| 12 x 64 x 0.05 | 2.0 |
| 12 x 104 x 0.05 | 2.5 |
| 8 x 4 x 0.07 | 0.6 |
| 8 x 8 x 0.07 | 0.8 |
| 8 x 9 x 0.07 | 0.9 |
| 8 x 13 x 0.07 | 1.0 |
| 8 x 15 x 0.07 | 1.2 |
| 8 x 19 x 0.07 | 1.5 |
| 8 x 23 x 0.07 | 1.6 |
| 12 x 28 x 0.07 | 2.0 |
| 12 x 33 x 0.07 | 2.2 |
| 24 x 21 x 0.07 | 2.25 |
| 12 x 49 x 0.07 | 2.5 |
| 12 x 70 x 0.07 | 2.9 |
| 12 x 86 x 0.07 | 3.0 |
| 12 x 96 x 0.07 | 3.5 |
| 12 x 92 x 0.07 | 3.65 |
| 12 x 138 x 0.07 | 4.0 |
| 12 x 160 x 0.07 | 4.5 |
| 12 x 186 x 0.07 | 5.0 |
| 12 x 441 x 0.07 | 8.0 |
| 16 x 40 x 0.1 | 3.0 |
