Single, multipair, PVC insulation, individual & collective screen, PVC sheath
| Armoured RE-Y(St)YSWAY |
||
|---|---|---|
| Diameter under armour | Outer diameter | Weight |
| (mm²) | (mm) | (kg/km) |
| 0.5 mm²/7 , RE-Y(St)YSWAY | ||
| 6.3 | 9.6 | 178 |
| 8.2 | 12.2 | 265 |
| 9 | 13.6 | 330 |
| 9.8 | 14.4 | 370 |
| 13.7 | 18.5 | 589 |
| 18.5 | 24.4 | 1,056 |
| 0.75 mm²/7 , RE-Y(St)YSWAY | ||
| 6.7 | 10.2 | 208 |
| 9.1 | 13.3 | 329 |
| 10 | 14.6 | 388 |
| 11.1 | 15.9 | 455 |
| 15.3 | 21 | 841 |
| 21 | 27.1 | 1,322 |
| 1 mm²/7 , RE-Y(St)YSWAY | ||
| 7.2 | 10.7 | 222 |
| 9.8 | 14 | 341 |
| 11.1 | 15.9 | 458 |
| 12.1 | 16.9 | 506 |
| 17 | 22.9 | 970 |
| 23.3 | 29.4 | 1,571 |
| 1.3 mm²/7 , RE-Y(St)YSWAY | ||
| 7.7 | 11.2 | 245 |
| 11 | 15 | 402 |
| 12.2 | 17 | 525 |
| 13.6 | 18.4 | 613 |
| 19.1 | 25 | 1,185 |
| 26.2 | 33.2 | 2,130 |
| 1.5 mm²/7 , RE-Y(St)YSWAY | ||
| 8.2 | 11.7 | 261 |
| 11.4 | 15.8 | 424 |
| 12.7 | 17.5 | 538 |
| 14.2 | 19.2 | 655 |
| 19.9 | 25.8 | 1,251 |
| 27.6 | 34.8 | 2,293 |
| Armoured RE-2X(St)YSWAY |
||
|---|---|---|
| Diameter under armour | Outer diameter | Weight |
| (mm²) | (mm) | (kg/km) |
| 0.5 mm²/7 , RE-2X(St)YSWAY | ||
| 6.3 | 9.6 | 183 |
| 8.3 | 12.2 | 280 |
| 9 | 13.6 | 336 |
| 9.8 | 14.4 | 376 |
| 13.7 | 18.5 | 593 |
| 18.5 | 24.4 | 1,060 |
| 0.75 mm²/7 , RE-2X(St)YSWAY | ||
| 6.7 | 10.2 | 200 |
| 9.2 | 13.3 | 319 |
| 10 | 14.6 | 383 |
| 11.1 | 15.9 | 449 |
| 15.3 | 21 | 827 |
| 21 | 27.1 | 1,294 |
| 1 mm²/7 , RE-2X(St)YSWAY | ||
| 7.2 | 10.7 | 220 |
| 9.9 | 14 | 358 |
| 11.1 | 15.9 | 450 |
| 12.1 | 16.9 | 510 |
| 17 | 22.9 | 974 |
| 23.3 | 29.4 | 1,523 |
| 1.3 mm²/7 , RE-2X(St)YSWAY | ||
| 7.7 | 11.2 | 242 |
| 11.1 | 15 | 383 |
| 12.2 | 17 | 512 |
| 13.6 | 18.4 | 596 |
| 19.1 | 25 | 1,115 |
| 26.2 | 33.2 | 2,049 |
| 1.5 mm²/7 , RE-2X(St)YSWAY | ||
| 8.2 | 11.7 | 260 |
| 11.5 | 15.8 | 420 |
| 12.7 | 17.5 | 531 |
| 14.2 | 19.2 | 646 |
| 19.9 | 25.8 | 1,230 |
| 27.6 | 34.8 | 2,251 |
